Infomir MAG 540 4K
Infomir MAG 540 4K
Brand: Infomir
Rating : Not Rated till now ! - Rate the product now or check reviews from customers
Plug version (if using)
EU
US/CA
UK
Choose packing size :
CHOOSE BIGGER PACK SIZE TO GET THE LOWEST PRICE
Quantity:
| Price per unit: | |
|---|---|
| Total price: Price is excluding VAT ! |
€ 77,00 |
| Check Shipping price |
Infomir MAG 540 is Linux IPTV settopbox with 4K resolution and connection via 100Mbit/s Ethernet port.
MAG 540 supports HEVC (H265).
Genuine Infomir MAG540 with processor Amlogic S905Y4 operating with Quad Core ARM Cortex - A35 CPU 2GHz
Interfaces
Audio & video
MAG 540 supports HEVC (H265).
Genuine Infomir MAG540 with processor Amlogic S905Y4 operating with Quad Core ARM Cortex - A35 CPU 2GHz
MAG540 is a new model of IPTV set-top box from Infomir. It is equipped with 1 GB of RAM and 4 GB of flash memory, which is enough for storing and playing high quality videos. MAG540 plays files with HEVC codec. This reduces the load on the network, even when it comes to streaming 4K content. Set-top box runs under Linux OS.
Supports 4K and HEVC, Linux OS, USB x 2 (3.0, 2.0), 1GB RAM, 4GB eMMC
Processor
|
Amlogic S905Y4 Quad-core ARM Cortex-A35, 2000 MHz | |
| Performance | 16500 DMIPS | |
| RAM | 1 GB | |
| Flash memory | 4 GB eMMC |
Software
| Operating system | Linux 4.9 |
| Middleware supported | Pre-integrated Ministra TV platform from Infomir. It is possible to integrate operator applications into the image, customize or completely replace the image. |
Interfaces
| HDMI 2.1, Ethernet 100 Mbps, USB 2.0x1, USB 3.0x1 |
Sources of media content
| PC and NAS in local network, Stream media protocols (RTSP, RTP, UDP, IGMP, HTTP), USB-devices |
Audio & video
| Audio codecs | MPEG L1 / L2 / L3l, AAC-LC, HE AAC V1 / V2, APE, FLAC, Dolby Digital Plus |
| Audio formats | AC3, ACC, APE, FLAC, M4A, MP3, OGG, WAV |
| Video modes | PAL, NTSC, 576p, 720p, 1080p, 1080i, 2160p |
| Video codecs | MPEG1 / 2 MP @ HL, MPEG4 part 2 (ASP), H.265 Main / Main 10@L5.1 High 2160p @ 60 fps (optional), H.264 AVC High@L5.1 2160p @ 30 fps, XviD, 3D video support |
| Video containers | TS, AVI, MPEG, MP4, MOV, MKV, M2TS, VOB |
| Image formats | JPEG, PNG, BMP, RAW |
| Subtitles | DVB, PGS, SRT, SSA / ASS, SUB, Teletext subs, WebVtt, Closed captions |
| Playlist formats | M3U, M3U8, PLS, CUE |
Included in Package :
- Infomir MAG 540 4K IPTV Receiver
- Power Supply Unit (EU/US or UK - choose during ordering)
- Remote Control Unit + Batteries
- HDMI Cable
- Short User Manual
- Infomir License Label
MAG 540 has only Ethernet connection, available also version with Wifi on board - Infomir MAG 540w3.
Shipping worldwide from EU stock, next day delivery.
